Smoothflow System Coating liquid supply system
Brochures
Features
- Transferring of large volumes of chemical solution at a constant flow
- Transferring of high-viscosity slurries
- Sanitary piping for easy disassembly, cleaning, and assembly
- Flow monitoring and control functions
- Explosion proof specification
Application examples
- Continuous, constant supply of coating liquid in optical film manufacturing processes
- Coating liquid supply in liquid crystal display manufacturing processes
- Precise, continuous supply of various coating solutions
Flow diagram Flow chart
Example of performance specifications
Please contact us for details of customized specications.
Tank Capacity | 50L + 20L |
---|---|
Pump feed volume | Up to 200mL/min |
Pump feed pressure | Up to 1.0MPa |
Weight | Approx. 290kg |
External dimensions (mm) | W1200 × H1650 × D800 |
