Smoothflow Pumps High-Pressure Type
Brochures
Features
High-pressure liquid transferring up to 50 MPa
Three different models are available to suit required flow rates and discharge pressures.
- 0.8L/min 50MPa
- 2.0L/min 20MPa
- 5.0L/min 10MPa
No Liquid Leakage
The pump head is completely sealed, which eliminates concerns about the liquid leaking or coming into contact with the atmosphere.
No Foreign Matter Contamination
This pump has no rotating or sliding parts, which can easily generate foreign matter. This eliminates concerns about the liquid being contaminated.
Resistant to Slurry
This pump transfers liquid gently, which eliminates concerns about the particles in the liquid being crushed or the pump suffering wear and tear.
Dry Running OK
This pump has no sliding parts, which eliminates concerns about heat caused by friction, the generation of abrasion debris, and seizing.
Pumping demo
Contact TACMINA to request a test using your actual liquid.
At TACMINA's "Liquid Solution Center <LABII>", pumps can be used to perform liquid transfer tests with the liquids that are actually used by our customers. Specialized technicians are available for consultations regarding liquid transfers, and a detailed report on the test results is also issued. This makes it possible for our customers to consider using liquids that are difficult to transfer and switching from other types of pumps with peace of mind.
Smoothflow System
We offer a system that you can count on, with a design that maximizes the potential of Smoothflow technology and a configuration that puts safety and maintainability first.
Specifications
| PLFXM2-04X | HPL-2 | HPL-5 | ||
|---|---|---|---|---|
| Max. discharge volume | L/min | 0.8 | 2 | 5 |
| L/h | 48 | 120 | 300 | |
| US G/h | 12.67 | 31.68 | 79.2 | |
| Max. discharge pressure | MPa | 50 | 20 | 10 |
| bar | 500 | 200 | 100 | |
| psi | 7250 | 2900 | 1450 | |
